ADAM Audio S6X Main Monitor

STATE OF THE ART TECHNOLOGY

ADAM Audio monitors have earned a worldwide reputation as the preeminent tool for sound engineers based on technological innovations that we’ve established in the field of loudspeaker technology.

X-ART Tweeter

ADAM Audio has improved upon the Air Motion Transformer utilizing superior geometries and materials to achieve unprecedented audio fidelity.
Learn more

X-ART Driver

A groundbreaking technological innovation with easily discernible superior performance and no technical flaws, the X-ART driver is clearly unequalled in the ...
Learn more

A/B Amplifier

We designed our own high frequency power amp to allow the new high frequency unit to live up to its unique talents.
Learn more

Woofer

HexaCone woofers are an integral component in most of ADAM’s monitors/speakers. The core is a honeycomb Nomex structure that makes them ...
Learn more

PW/M

ADAM units use the new technology for both the amp and the power supply section (i.e. no more transformers) combined with state of the art input and filter s...
Learn more
ADAM Audio Technologies - Impulse Coupling

Impulse Coupling

Impulse Coupling is the rock solid connection that improves the situation of the driver in a comparable way.
Learn more
SEE MORE TECHNOLOGIES

Approved BY OUR PROFESSIONAL COMMUNITY

„ADAM is pushing the standard for transparency in a monitor system to new levels.”

Pro Sound News

ADAM Audio S6X in use

Press Reviews

Pro Sound News
Download
PDF (108 KB)

Features & Benefits

Product Feature
Benefit to the customer
X-ART tweeter, handmade in Berlin
  • Allows longer operation with fewer signs of fatigue
  • Their breakup is prevented by the folded diaphragms, distortions are effectively reduced to a minimum
  • Advanced dynamic range due to acoustically effective diaphragm surface that is 2.5 times bigger (compared to a classic tweeter according to the piston principle)
The air velocity ratio of 4:1 during the sound generation by folded X-ART membrane

Direct, fast response in the high-range even with complex transients

Ultra-light but extremely dimensionally stable woofer material (HexaCone)

Excellent transient response even at high sound levels without breakup of the diaphragm

4-way system with 2 x 12" woofer and 2 x 7.5” midrange

Very high resolution of the stereo image and extremely wide stereo base

Spacious bass reflex ports on the front

Bass reproduction with very low compression

Highly efficient PWM amplifiers

Low-distortion amplification at both low and high volume levels

Linear frequency response of 23 Hz to 50 kHz

Unbiased reproduction in a wide frequency band

Maximum peak sound pressure per pair in 1 m ≥ 133 dB

Powerful, compression-free sound reproduction even at very high sound levels

Sophisticated room acoustic adjustments

Allows optimal adaptation to acoustically difficult listening environments or individual preferences

Analog XLR input

Optimized for balanced line signals

Directional sound radiation in vertical plane

Reduction of early reflections on the surfaces of, e.g. mixing consoles, desks, etc.

2 years warranty with optional extension to 3 years with the registration of the product

Full repair service if required for 5 years

Technical Data

Woofer

Number2
Basket Ø12" (305 mm)
Voice Coil Ø3" (75 mm)
Cone MaterialHexaCone

Midrange (cone)

Number2
Basket Ø7.5" (186 mm)
Voice Coil Ø2" (50 mm)
Cone MaterialHexaCone

Midrange

Number2
TypeX-ART
Diaphragm Area2 x 26 inch² (16800 mm²)
Equiv. Diaphragm Ø2 x 5.5" (146 mm)
Velocity Transform Ratio3.5:1
Diaphragm Weight0.7 g

Tweeter

Number1
TypeX-ART
Diaphragm Area4 inch² (2420 mm²)
Equiv. Diaphragm Ø2" (56 mm)
Velocity Transform Ratio4:1
Diaphragm Weight0.17 g

Built-in Amplifiers

Woofer2
TypePWM
Amp. Power RMS / Music500 W / 700 W
Midrange (cone)2
TypePWM
Amp. Power RMS / Music250 W / 350 W
Midrange2
TypePWM
Amp. Power RMS / Music250 W / 350 W
Tweeter1
TypePWM
Amp. Power RMS / Music250 W / 350 W

Control Panel

Input Sensitivity±10 dB
EQ 80 Hz (Q / Hz / Level)3 x 0.2 - 20 / 20 - 200 / ±12 dB
High Shelf EQ > 6 kHz±6 dB
Low Shelf EQ < 150 Hz±6 dB
Sub Gain±4 dB
Mid-Woofer Level±2 dB
Mid Level±2 dB
Tweeter Gain±4 dB

Input Connectors

AnalogXLR

General Data

PanelFront
X-Curve FilterYes
Frequency Response23 Hz - 50 kHz
THD 90 dB / 1 m > 100 Hz≤0.5 %
Max. SPL with sine wave acoustic 100 Hz to 3 kHz at 1 m≥123 dB
Max. SPL per pair at 1 m≥133 dB
Crossover Frequencies85 / 800 / 3100 Hz
Input Impedance10 kOhm
Weight213.8 lb (97 kg)
Magnetically ShieldedNo
Height x Width x Depth28.5" (720 mm) x 37" (940 mm) x 19.5" (490 mm)
Warranty5 years (2 years warranty plus 3 years optional with product registration)
Delivery ContentsPower cord, manual
