A77XNear-/Midfield Monitor

Archived Product
ADAM Audio A77X Studio Monitor

The A77X is no longer being produced. Please have a look at its successor: The ADAM Audio A77H!

STATE OF THE ART TECHNOLOGY

ADAM Audio monitors have earned a worldwide reputation as the preeminent tool for sound engineers based on technological innovations that we’ve established in the field of loudspeaker technology.
SEE MORE TECHNOLOGIES

Approved BY OUR PROFESSIONAL COMMUNITY

So there we have the ADAM A77X: an extremely able active monitor that´s capable of accurately reproducing frequencies from 38Hz to 50kHz in a seemingly effortless manner, even when being run at some pretty serious levels. This all comes with a price tag that actually represents very good value for money, given the level of performance that the ADAM A77X delivers.

Bob Thomas
Sound on Sound

ADAM Audio A77X in use

Press Reviews

Interface [Dutch]
Download
PDF (153 KB)
Recording Magazine [English]
Download
PDF (1.7 MB)
DrumXound [German]
Delamar.de [German]
MIX [English]
Download
PDF (5.9 MB)
Sound & Recording [English]
Download
PDF (130 KB)
Sound & Recording [German]
Download
PDF (1.7 MB)
Sound On Sound [German]
Download
PDF (140 KB)
Sound On Sound [English]
Download
PDF (2.1 MB)
Ryan "Fluff" Bruce [English]
Audio Technology [English]
Download
PDF (92 KB)
MusicTech [English]
Download
PDF (473 KB)
Audiomedia [English]
Download
PDF (117 KB)
Studio-Speakers.com [English]
John Browne [English]
davespeakmanmusic [English]

Technical Data

Woofer

Number2
Basket Ø7" (175 mm)
Voice Coil Ø1.5" (38 mm)
Cone MaterialCarbon / Rohacell / Glass Fiber

Tweeter

Number1
TypeX-ART
Diaphragm Area4 inch² (2420 mm²)
Equiv. Diaphragm Ø2" (56 mm)
Velocity Transform Ratio4:1
Diaphragm Weight0.17 g

Built-in Amplifiers

Woofer1
TypePWM
Amp. Power RMS / Music100 W / 150 W
Subwoofer1
TypePWM
Amp. Power RMS / Music100 W / 150 W
Tweeter1
TypeA/B
Amp. power RMS / music50 W / 75 W

Control Options

Input Sensitivity-∞ to +14 dB
High Shelf EQ > 5 kHz±6 dB
Low Shelf EQ < 300 Hz±6 dB
Tweeter Gain±4 dB

Input Connectors

AnalogXLR / RCA

General Data

Frequency Response38 Hz - 50 kHz (-10 dB)
THD 90 dB / 1 m > 100 Hz≤0.5 %
Max. SPL with sine wave acoustic 100 Hz to 3 kHz at 1 m≥114 dB
Max. SPL per pair at 1 m≥122 dB
Crossover Frequencies0.4 / 3.0 kHz
Input Impedance30 kOhm
PanelFront
Weight28.2 lb (12,8 kg)
Magnetically ShieldedNo
Height x Width x Depth9.5" (235 mm) x 21" (530 mm) x 11" (280 mm)
Warranty5 years (2 years warranty plus 3 years optional with product registration)
Delivery ContentsPower cord, manual

Additional information
